Shell and Tube Heat Exchanger for USA Petrochemical Facility
Project Overview:
In Q4 2025, our engineering and manufacturing teams successfully delivered a custom-engineered shell and tube heat exchanger to a major petrochemical facility located on the U.S. Gulf Coast in Texas. This high-performance unit is designed to withstand extreme temperature and pressure conditions, and was fabricated in full compliance with ASME Section VIII, Division 1 (U‑Stamp certified) and TEMA Class R standards. The project delivery precisely aligned with the client's scheduled maintenance turnaround, effectively resolving their production capacity bottleneck. This case study details our end‑to‑end capabilities—from design and manufacturing to final delivery—demonstrating how we successfully supplied equipment that meets the highest international standards to the U.S. market within a tight schedule.
Key Results at a Glance:
-
On-time delivery within client's critical maintenance window
-
Zero non-conformances during third-party inspection
-
18.5 MM Btu/hr heat transfer duty delivered
The Client & Challenge:
The client operates multiple processing units along the U.S. Gulf Coast, one of the world's most concentrated petrochemical regions. Their existing shell tube heat exchanger in the olefins production unit was approaching end-of-life, exhibiting significant fouling and reduced thermal efficiency that threatened overall plant throughput.
Critical requirements for the replacement unit included:
-
Custom thermal design for high-temperature, high-pressure process conditions
-
Corrosion-resistant materials suitable for aggressive process media
-
Full compliance with ASME BPVC Section VIII and TEMA Class R standards
-
Strict dimensional constraints matching existing foundation and piping
-
Delivery aligned with the facility's planned maintenance turnaround
Our Engineered Solution:
Our engineering team conducted comprehensive thermal and mechanical analysis to develop an optimized shell and tube heat exchanger design. The specifications are as below:
Key Design Features:
-
Segmental baffle arrangement optimized for enhanced heat transfer and reduced fouling
-
316L stainless steel tubes providing excellent corrosion resistance
-
Removable tube bundle design facilitating future maintenance
-
Full radiographic examination (RT) of all pressure-retaining welds
-
Hydrostatic testing at 1.5x design pressure prior to shipment
Manufacturing & Quality Assurance:
Fabrication was completed at our ISO 9001:2015 certified manufacturing facility, equipped with:
-
Automated tube-to-tubesheet welding with full penetration
-
Precision tube rolling and expansion
-
In-house post-weld heat treatment (PWHT) furnace
-
Full NDT capabilities including RT, UT, MT, and PT
Each fabrication stage underwent rigorous quality control, with third-party inspection conducted by an authorized ASME inspection agency. The unit received full ASME U-Stamp certification prior to shipment.
The unit was shipped via breakbulk vessel from Shanghai to the Port of Houston, with specialized rigging for safe transit. Our technical team provided on-site support for unloading, positioning, and commissioning guidance.
Results & Performance:
The shell and tube heat exchanger was successfully installed during the client's planned turnaround and commissioned on schedule:
-
On-time delivery meeting the client's critical maintenance window
-
Zero non-conformances identified during inspection
-
Reduced pressure drop improving overall system energy efficiency
"The team delivered a high-quality product that met all our technical requirements and arrived exactly when we needed it. Their engineering support throughout the project was exceptional."
— Senior Procurement Manager, U.S. Petrochemical Operator
Why Us?
-
ASME U-Stamp certified
-
TEMA-compliant design
-
End-to-end project management from design to delivery
-
Proven export experience
-
Competitive pricing with uncompromising quality
